Blue

ZKSJ Circulation Pool Pump Blue,Automatic cycle filtering, automatic cycle, high temperature resistance, strong pollution effect.

Impeller： Closed Impeller
Max head： 3M-10M
Weight：
Rated voltage： 24Vdc
Max flow： 30000L/H
Dimension：

Contact Us

Close

Consulting

Customer service：86-755-27811557

Description

Electrical parameters

Model	Blue3000	Blue4000	Blue6000	Blue8000	Blue10000	Blue12000		Blue20000	Blue30000
Flow rate	3000L/H	4000L/H	6000L/H	8000L/H	10000L/H	12000L/H		20000L/H	30000L/H
Head	3.5M	4M	5M	6M	5M	6M		6M	8M
Max comnsumption	40W	50W	70W	85W	105W	115W		150W	220W
Min comnsumption	10W	10W	20W	20W	30W	30W		30W	50W
Voltage	DC 24V	DC 24V			DC 24V			DC 24V
Dimension	12071130	16485161			19399191			27013688
Outlet/Inlet	20MM/25MM	25MM/32MM			32MM/40MM			63MM THREAD

Dimensions of pump

图片关键词

For US customers, please contact our US agent Sevenports directly.
Here is the website link:

https://sevenports.com
https://sevenports.com/platinum-blue-series-pumps/
https://sevenports.com/platinum-slim-wave-maker/
